Recommended by Piscinarium
Heat pump with a compressor featuring full inverter technology for heating residential pool water.
Integrated connectivity with the Fluidra Pool mobile app .
Silent and efficient , R32 refrigerant and heating priority.
Minimum operating temperature: -5°C
Available in 6 models with power from 5 to 20 kW .
Eco Elyo is equipped with Full Inverter technology that automatically adapts the speed of its compressor and fan to heating needs, reducing energy consumption and ensuring quieter operation.
This technology offers 3 operating modes:
- Boost: Rapid temperature increase, ideal at the beginning of the season
- Smart: Smart mode that allows automatic adjustment based on temperature.
- Ecosilence: Reduces the power of the heat pump, for energy savings and silent operation.
Eco Elyo operates at -5°C, outside air temperature, to extend the bathing season.
This low-temperature operation allows you to enjoy the pool even in spring and autumn.
In addition, thanks to its 6 power levels, Eco Elyo can heat both small and large pools very quickly.
We've equipped all our models with Bluetooth and Wi-Fi connectivity so they can be optimally managed.
The Fluidra Pool app allows you to control all parameters remotely, 24 hours a day, for maximum peace of mind.
Full Inverter technology that guarantees silent operation and optimal energy efficiency, with three operating modes:
Boost: Maximum power for a quick warm-up at the start of the season.
Smart: automatically regulates power between Ecosilence and Boost modes.
Ecosilence: offers the lowest energy consumption and the lowest noise level.
Integrated Wi-Fi connectivity via the free Fluidra Pool mobile app.
Operation guaranteed down to a minimum temperature of -5°C.
Modern and robust design: ABS plastic housing with a new injection-molded fan grille and a galvanized steel protective grille for the evaporator.
It uses R32 refrigerant, which is more ecological and efficient.
Includes heating priority function, which allows control of the filtration pump.
It has an automatic defrost system and a titanium heat exchanger, compatible with pools treated with saline chlorination.
LCD display for simple and intuitive control.
It incorporates a rotary vane compressor for optimal performance.
Included accessories:
Protective winter cover.
PVC hydraulic connectors Ø 50 mm.
Condensation drainage kit.
| Model | ECO ELYO-05 | ECO ELYO-07 | ECO ELYO-09 | ECO ELYO-13 | ECO ELYO-15 | ECO ELYO-20 |
| Reference | 76657 | 76658 | 76659 | 76660 | 76661 | 76662 |
| Rating Standard EN 17645 | TO | TO | TO | TO | TO | TO |
| SCOP Standard EN 17645 | 7.5 | 7.5 | 8 | 9.6 | 7.7 | 8.5 |
| Recommended water flow rate (m³/h) | 3 | 3 | 4 | 5 | 6 | 7 |
| Power supply | Bun 220-240 V / 1 / 50-60 Hz |
Bun 220-240 V / 1 / 50-60 Hz |
Bun 220-240 V / 1 / 50-60 Hz |
Bun 220-240 V / 1 / 50-60 Hz |
Bun 220-240 V / 1 / 50-60 Hz |
Bun 220-240 V / 1 / 50-60 Hz |
| Nominal absorbed power (A) | 4.9 | 4.9 | 6.3 | 8 | 10.2 | 13.6 |
| Maximum absorbed power (A) | 8 | 8 | 9 | 13 | 16 | 19 |
| Power cable (mm²) * | 3 x 2.5 | 3 x 2.5 | 3 x 2.5 | 3 x 2.5 | 3 x 4 | 3 x 4 |
| Refrigerant fluid | R32 | R32 | R32 | R32 | R32 | R32 |
| Amount of refrigerant (kg) | 0.3 | 0.3 | 0.45 | 0.6 | 0.7 | 1.0 |
| Acoustic power (max-min) (dBA) ** | 59 - 47 | 59 - 47 | 64 - 51 | 64 - 51 | 67 - 55 | 70 - 57 |
| Sound pressure at 10m (max-min) (dBA) ** | 28 - 16 | 28 - 16 | 33 - 20 | 33 - 20 | 36 - 24 | 39 - 26 |
| HEATING PERFORMANCE | ||||||
| Air 26°C / Water 26°C / Humidity 80% | ||||||
| Power input (max-min) (kW) | 5.5 - 1.5 | 7 - 2 | 9.5 - 2.3 | 13 - 2.4 | 15 - 2.5 | 20 - 7.6 |
| Power consumed (max-min) (kW) | 0.9 - 0.1 | 1.1 - 0.15 | 1.4 - 0.2 | 2 - 0.1 | 2.5 - 0.15 | 3.6 - 0.6 |
| COP (coefficient of performance) | 6.1 - 14.4 | 6.5 - 13.4 | 6.7 - 13.5 | 6.5 - 16.4 | 6 - 16.3 | 5.5 - 12.3 |
| Air 15°C / Water 26°C / Humidity 70% | ||||||
| Power input (max-min) (kW) | 3.9 - 1.1 | 5.5 - 1.4 | 7 - 1.5 | 9 - 1.7 | 11 - 1.9 | 14.8 - 5.4 |
| Power consumed (max-min) (kW) | 0.8 - 0.1 | 1.1 - 0.2 | 1.3 - 0.2 | 1.9 - 0.2 | 2.3 - 0.25 | 3.2 - 0.72 |
| COP (coefficient of performance) | 5.2 - 8 | 5.2 - 6.4 | 5.3 - 6.6 | 4.8 - 7.8 | 4.8 - 7.7 | 4.6 - 7.5 |
| DIMENSIONS AND WEIGHT | ||||||
| Dimensions (Length x Height x Depth) (mm) | 831 x 654 x 393 | 831 x 654 x 393 | 831 x 654 x 393 | 831 x 654 x 393 | 914 x 654 x 393 | 1111 x 754 x 413 |
| Approximate weight (kg) | 38.5 | 38.5 | 41.5 | 46 | 52.5 | 66 |
This product comes in different variations. Please check the table to find the one that best suits your needs for AstralPool Eco Elyo Full Inverter Heat Pump.
At Piscinarium, we are here to help. If you have any doubts, contact us via online chat, email, WhatsApp, or phone. We will try to get back to you as soon as possible.
Please note that during high season, we might take a bit longer than we would like. We apologize in advance; in these cases, reaching out in writing is best so we can get back to you as soon as we can.
| Reference | Model / Specification |
|---|---|
76662
|
ECO ELYO-20 |
76661
|
ECO ELYO-15 |
76660
|
ECO ELYO-13 |
76659
|
ECO ELYO-09 |
76658
|
ECO ELYO-07 |
76657
|
ECO ELYO-05 |
Astralpool is specialized in the manufacture and distribution of all kinds of articles and accessories for swimming pools (private and public). In its catalog you will find from pool cleaners, filters, showers, ladders, purification equipment, salt electrolysis equipment, cleaning equipment, ... to saunas and spas. AstralPool has the most complete range of products for your pool.
